PLASMA 60S
The JÄCKLE Plasma 60 has a very good price-performance ratio. It is the ideal equipment for craft, agriculture, motor vehicles, etc. The fixed cutting current of 60 Amp. Is suitable for cutting up to a max. Sheet thickness of 20 mm.
PLASMA 60 - single-stage
Plasma gas: compressed air
Plasma burner with single connection
High-frequency ignition
thermal overload protection
very robust and reliable design
Very service-friendly
Technical specifications
Mains voltage 400 V, 3 phases
Fuse 20 A slow
Power consumption 18.0 kVA
Adjustment range 60 A
Open circuit voltage 320 V
Quality cut 15 mm
Separating cut 20 mm
Insulation class H (180 ° C)
Weight 75.0 kg
Duty cycle 40 35% 60 A / 104 V
Degree of protection IP 23
Compressed air supply 5.5 bar, 160 l / min
Dimensions L x W x H (mm) 480 x 540 x 920
