SQUAREARC 5006
SQUAREARC JESS
MADE IN GERMANY
3 YEARS WARRANTY
MADE IN GERMANY
3 YEARS WARRANTY
- Advantages and features
- Flexibly configurable - tailored to your needs
- Gas or water cooled
- Portable or mobile
- Remote control by hand and foot controls
- Easy torch change thanks to quick-release fasteners on the front of the device
- Also available as an automatic power source
- Intuitive and fast operation
- The push-turn controller enables easy operation
- The set parameter is visualized
- Easy access to functions
- Clear feedback on type, value and dimensions
- Reliable setting - the user is always informed
- Simple operation saves time and leads to a good welding result faster
- Intuitive setting of the process parameters in their chronological order
- Quick and easy adaptation to welding tasks
- Up to 499 jobs for recurring tasks and reproducible results
- Your advantages in DC mode
- Higher productivity and narrow visible seams thanks to Rapid TIG Technology (RTT)
- Significantly reduced component distortion through RTT and Multipuls
- TIG Speedspot for quick and precise stapling
- Up to 25% faster
- Stable arc from 5 amps
- Reduced rework due to fewer tarnish colors
- Less arc deflection thanks to 20 kHz technology
- Stapling of stainless steels with almost no tarnish
- Your advantages in AC mode
- Optimal arc properties for aluminum and aluminum-bronze welding
- Flexible modeling of the arc by varying the current curves and the mixed arc
- The choice is yours: sine, square and trapezoid * curves can either be welded individually or combined with one another
- Whether softer and quieter or faster and more strongly bundled - you can model the right arc for every requirement
- Greatest optimization potential for your individual welding process
Technical data: | SQUAREARC 5006 |
Mains voltage | 400 V |
Fuse slow | 32 A |
TIG setting range | 3 - 500 A |
Open circuit voltage | 59 V |
Duty cycle 60% TIG / manual | 400 A / 350 A |
Duty cycle 100% TIG / manual | 230 A / 220 A |
Protection class | IP 23 S |
Power consumption | 20.1kVA |
Dimensions with trolley L x W x H (mm) | 1050 x 500 x 1100 |
Weight | 124 kg |
